Setting up an IPsec VPN with dynamic IP addresses on a FortiGate firewall can seem daunting, but it's totally achievable! This guide will walk you through the process, breaking it down into manageable steps. We'll cover everything from understanding the basics to configuring your FortiGate for dynamic IPsec. So, if you're ready to dive in and get your VPN up and running, let's get started!

Understanding Dynamic IPsec VPN

Before we jump into the configuration, let's quickly define what dynamic IPsec VPN means and why it's useful. Unlike static IPsec VPNs where both ends have fixed, unchanging IP addresses, dynamic IPsec deals with scenarios where one or both ends of the VPN connection have IP addresses that can change. This is super common for remote users or small offices that connect to the internet via DHCP, which assigns IP addresses automatically. These addresses can change periodically, depending on the ISP's configuration or when the user restarts their modem.

The challenge with dynamic IPs is that traditional IPsec configurations rely on knowing the IP addresses of both ends in advance. When one IP changes, the VPN tunnel breaks. That's where Dynamic DNS (DDNS) comes to the rescue! A Dynamic DNS service allows you to associate a domain name (like myvpn.example.com) with a dynamically changing IP address. When your IP changes, the DDNS service automatically updates the DNS record, so your FortiGate can always find the other end of the VPN using the domain name, rather than a specific IP.

Using dynamic IP addresses in IPsec VPNs offers several advantages. First and foremost, it enables connectivity for users and locations with dynamic IPs, which is incredibly convenient for remote workers, branch offices with standard internet connections, or anyone who doesn't have a static IP address. This flexibility is crucial in today's world where remote work is more prevalent than ever. Secondly, it can potentially reduce costs, as static IP addresses often come with a higher price tag from internet service providers. By leveraging dynamic IPs, you can save money while still maintaining a secure VPN connection.

Prerequisites

Before we start configuring your FortiGate, ensure you have the following prerequisites in place:

• A FortiGate firewall: Obviously! Make sure it's running a relatively recent version of FortiOS.
• A Dynamic DNS (DDNS) account: Sign up for a DDNS service like DynDNS, No-IP, or similar. Configure your router or computer on the dynamic IP end to update the DDNS record whenever the IP address changes. Most routers have built-in support for common DDNS providers.
• Basic networking knowledge: Familiarity with IP addressing, subnets, and routing will be helpful.
• Administrative access to your FortiGate: You'll need to be able to log in and make configuration changes.

Configuring the FortiGate for Dynamic IPsec VPN

Now, let's get into the fun part – configuring your FortiGate. We'll walk through the necessary steps, using both the web-based GUI and the command-line interface (CLI) to illustrate different configuration methods.

Phase 1 Configuration

Phase 1 establishes the initial secure connection between the two VPN endpoints. This phase involves negotiating encryption algorithms, authentication methods, and key exchange parameters. Here's how to configure Phase 1 on your FortiGate:

Using the GUI:

1. Go to VPN > IPsec Wizard. This wizard simplifies the initial configuration.
2. Give your VPN a descriptive name. Choose Custom as the template type.
3. Set the Remote Gateway type to Dynamic DNS. Enter the DDNS hostname of the remote peer (e.g., remote.example.com).
4. Select the Interface that will be used for the VPN connection (usually your WAN interface).
5. Choose an Authentication Method. Preshared Key is the most common for simplicity, but Certificates are more secure for production environments. If using a Preshared Key, enter a strong, complex key.
6. Configure the Phase 1 Proposal. This defines the encryption and authentication algorithms to be used. Ensure both sides of the VPN are configured with the same proposal. Common settings include:
   • Encryption: AES256
   • Authentication: SHA256
   • DH Group: Group14 (2048 bit)
   • Key Lifetime: 86400 seconds (24 hours)
7. Click Next to move to Phase 2 configuration.

Using the CLI:

config vpn ipsec phase1-interface
    edit "your_vpn_name"
        set interface "wan1"  // Replace wan1 with your WAN interface
        set mode main
        set dhgrp 14
        set proposal aes256-sha256
        set psksecret <your_preshared_key>
        set peertype any  // Important for dynamic IP
        set net-device enable
        set remote-gw <remote.example.com> // Your DDNS hostname
    next
end

• set interface "wan1": Specifies the interface used for the VPN.
• set mode main: Sets the IKE mode to Main mode, which is generally preferred for dynamic IPsec.
• set dhgrp 14: Configures Diffie-Hellman group 14 for key exchange.
• set proposal aes256-sha256: Sets the encryption and authentication algorithms.
• set psksecret <your_preshared_key>: Defines the preshared key.
• set peertype any: This is crucial for dynamic IP scenarios. It allows the FortiGate to accept connections from any peer IP address, as long as the preshared key matches. Without this setting, the VPN will likely fail when the remote IP changes.
• set remote-gw <remote.example.com>: Specifies the DDNS hostname of the remote peer.

Phase 2 Configuration

Phase 2 establishes the secure communication channel for data transfer after Phase 1 has successfully completed. It defines the encryption and authentication algorithms used for the actual data packets. Here's how to configure Phase 2:

Using the GUI:

1. In the IPsec Wizard, you should now be on the Phase 2 configuration page.
2. Define the Local and Remote Networks. This specifies which networks are allowed to communicate through the VPN tunnel. If you want all traffic to go through the tunnel, set both to 0.0.0.0/0 (any).
3. Configure the Phase 2 Proposal. Similar to Phase 1, ensure the settings match the remote peer. Common settings include:
   • Protocol: ESP
   • Encryption: AES256
   • Authentication: SHA256
   • PFS: Enable (using DH Group 14 is recommended)
   • Key Lifetime: 3600 seconds (1 hour)
4. Click Create to finish the wizard.

Using the CLI:

config vpn ipsec phase2-interface
    edit "your_vpn_name_phase2"
        set phase1name "your_vpn_name"  // Reference the Phase 1 configuration
        set proposal aes256-sha256
        set pfs enable
        set dhgrp 14
        set src-addrssubnet 192.168.1.0 255.255.255.0 // Local subnet behind fortigate
        set dst-addrssubnet 192.168.2.0 255.255.255.0 // Remote subnet
    next
end

• set phase1name "your_vpn_name": Links this Phase 2 configuration to the Phase 1 configuration we created earlier.
• set proposal aes256-sha256: Sets the encryption and authentication algorithms for Phase 2.
• set pfs enable: Enables Perfect Forward Secrecy (PFS) for enhanced security. PFS generates a new session key for each session, preventing an attacker who compromises one key from decrypting past sessions.
• set src-addrssubnet and set dst-addrssubnet: Specifies the source and destination subnets that are allowed to communicate through the VPN.

Firewall Policies

Now that the IPsec VPN is configured, you need to create firewall policies to allow traffic to flow through the tunnel. You'll need two policies:

• One policy to allow traffic from your internal network to the VPN tunnel.
• Another policy to allow traffic from the VPN tunnel to your internal network.

Using the GUI:

1. Go to Policy & Objects > Firewall Policy.
2. Click Create New.
3. Policy 1 (Internal to VPN):
   • Name: Internal-to-VPN
   • Incoming Interface: Your internal interface (e.g., lan)
   • Outgoing Interface: The IPsec VPN interface you created (e.g., your_vpn_name).
   • Source: Your internal network (e.g., 192.168.1.0/24).
   • Destination: The remote network (e.g., 192.168.2.0/24 or all if you want to allow all traffic).
   • Schedule: always
   • Service: ALL
   • Action: ACCEPT
   • Enable NAT if needed. It depends if the other peer has a route back to your internal IP range or not. If it does not, NAT needs to be enabled.
4. Policy 2 (VPN to Internal):
   • Name: VPN-to-Internal
   • Incoming Interface: The IPsec VPN interface (e.g., your_vpn_name).
   • Outgoing Interface: Your internal interface (e.g., lan).
   • Source: The remote network (e.g., 192.168.2.0/24 or all if you want to allow all traffic).
   • Destination: Your internal network (e.g., 192.168.1.0/24).
   • Schedule: always
   • Service: ALL
   • Action: ACCEPT
5. Make sure the policies are enabled.

Using the CLI:

config firewall policy
    edit 1  // Policy ID (increment for each new policy)
        set name "Internal-to-VPN"
        set srcintf "lan"  // Your internal interface
        set dstintf "your_vpn_name"  // The IPsec VPN interface
        set srcaddr "192.168.1.0/24"  // Your internal network
        set dstaddr "192.168.2.0/24"  // The remote network
        set action accept
        set schedule always
        set service ALL
    next
    edit 2  // Policy ID
        set name "VPN-to-Internal"
        set srcintf "your_vpn_name"
        set dstintf "lan"
        set srcaddr "192.168.2.0/24"
        set dstaddr "192.168.1.0/24"
        set action accept
        set schedule always
        set service ALL
    next
end

Remember to adjust the interface names, source/destination addresses, and other settings to match your specific network configuration.

Testing and Troubleshooting

After configuring the FortiGate, it's time to test the VPN connection. Here are some steps you can take:

• Check the VPN Status: In the FortiGate GUI, go to VPN > IPsec Monitor to see if the VPN tunnel is up and active. You should see green indicators.
• Ping Test: From a device on your internal network, try pinging a device on the remote network (and vice versa). If the pings are successful, the VPN is likely working correctly.
• Traceroute: Use traceroute to see the path traffic is taking. This can help verify that traffic is indeed going through the VPN tunnel.
• Firewall Logs: Check the FortiGate's firewall logs for any denied traffic that might be related to the VPN. This can help identify any misconfigurations in your firewall policies.

If you encounter issues, here are some common troubleshooting tips:

• Verify Preshared Keys: Double-check that the preshared keys on both ends of the VPN match exactly. Even a single character difference will prevent the connection from establishing.
• Check Phase 1 and Phase 2 Settings: Ensure that the encryption, authentication, and DH group settings in Phase 1 and Phase 2 are identical on both sides of the VPN.
• Firewall Policies: Make sure your firewall policies are correctly configured to allow traffic in both directions.
• Routing: Verify that you have proper routing configured on both networks so that traffic knows how to reach the other side of the VPN.
• DDNS Resolution: Confirm that the DDNS hostname is resolving to the correct IP address. You can use the nslookup command to check this.

Conclusion

Setting up a dynamic IPsec VPN on a FortiGate requires careful configuration, but it's a powerful way to securely connect networks with dynamic IP addresses. By following the steps outlined in this guide, you should be able to get your VPN up and running smoothly. Remember to pay close attention to the Phase 1 and Phase 2 settings, firewall policies, and routing configuration. With a little patience and attention to detail, you can create a robust and secure VPN connection for your network. Good luck, and happy networking!
